hd PC150

Pendant Loudspeaker

  • passive 2-way pendant speaker with 3.5 “+ 1” tweeter
  • timeless design
  • superb speech intelligibility
  • Integrated transformer with 5-stage mode switch for 8 Ω, Off or 100 V (30 | 15 | 7.5 W)
  • precise, even radiation 80° conical
  • extended frequency response for background music

The hd PC150 is a passive 2-way pendant loudspeaker, equipped with a 3.5“ woofer and a coaxially arranged 1“ tweeter, with a linear frequency response and extended bass reproduction. It can be operated via any low-impedance power amplifier or in existing existing 70V / 100V networks – even without a DSP – and makes the hd PC150 the ideal solution for decentralized and large-scale sound reinforcement tasks such as in hotels, restaurants, shopping centers or airports.

The 5-stage mode switch enables the selection of the operating mode from low-resistance operation with 8 Ω, mute or high-resistance operation with 30 W | 15W | 7.5W in 100V networks. The hd PC150 can be easily suspended from the ceiling thanks to the removable brackets. The shapely housing with bass reflex tuning allows high-performance bass reproduction.

Model hd PC150
Principle Coaxialloudspeaker
Transducers 1x 3,5″ woofer + 1x 1″ tweeter
Crossover 4 kHz
Power handling capacity (RMS/Peak) 40 W / 55 W
Frequency range 65 Hz – 22 kHz
Sensitivity (1 W / 1 m) 88 dB
Max. sound pressure (1 m) 111 dB
Nominal dispersion angle conical 80°
Impedance (LowZ) 8 Ohms
Transformer (HighZ) 30 W | 15W | 7.5 W @ 100V
15 W | 7.5W | 3.8W @ 70V
Connection 1x clamp terminal
Dimensions (Ø x H) 150 x 250 mm
Weight 2.5 kg
Enclosure Powder-coated aluminium cylinder black
removable steel grille
clamp terminal
5-stage mode switch (Low-Z Off|High-Z)
incl. bracket

Applications

  • public buildings, conference and media technology
  • restaurants, bars, airports, train stations, home cinema
